KPS120CFCS

KPS 120 CF CS (Dk-SE-NO)

Blast chillers

The KPS 120 CF CS (Dk-SE-NO) is a [[att_title]], designed for seamless integration into professional workflows. Its outer dimensions (W x D x H) are [[att_width|0|none|none|none|]] x [[att_depth|0|none|none|none|]] [[att_height|0|,|.|none|]] mm.

CONNECTED KITCHEN MANAGEMENT
Wi-Fi connectivity and an Ethernet port allow the system to connect with modern kitchen monitoring platforms and enable easy access to operational information, such as HACCP data.

Discontinued
Get quote View spec sheet

Key features

Food Safe

Food items are handled in full compliance with the HACCP guidelines. HACCP alarms and an automatic shift to ‘storage mode’ are useful extras to help you to ensure the highest food safety at all times.



High Food Quality

Taste, texture, appearance as well as vitamins and nutrient content are preserved. The use of IFR function also protects against surface freeze damage.



Versatility

Offers different operational modes: IFR operation, time or temperature controlled chill cycle. Up to 20 customized cycles can be stored.



Modularity and Scalability

Available as reach-in, roll-in or roll-through models for small or big scale operations. Part delivery or turn key.

Specifications

Specification Value
Item number KPS120CFCS
Model name KPS 120 CF CS (Dk-SE-NO)
Brand Gram
Please observe It is necessary to connect this unit to an external drain. The product is delivered unassembled, in parts on two pallets
Width (packed) 1630 mm
Width inside 1430 mm
Depth (packed) 1230 mm
Depth inside 1030 mm
Height (packed) 2130 mm
Height inside 2030 mm
Volume (packed) 4.2704 m³
Energy consumption - Chilling (kWh/kg) 0.06 kWh/kg
Exterior Stainless Steel
Interior Stainless
Gross weight 260 kg
Insulation type Cyclopentane
Power supply 230V, 50Hz
Temperature range 0/+10°C
Chilling capacity 120
Refrigeration capacity 8500
Refrigerant type Standard remote model prepared for R404A. Optionally can be prepared for R407A/R407F/R448A/R449A/R452A/R455A
SKU KPS120CFCS

Documentation

Documentation
Declaration of conformity Download
Installation manual Download
Instruction manual Download
