FM-120KE(SA) Flaker, Self-Contained

Ice makers

This Hoshizaki FM-120KE(SA) is a Flaker, Self-Contained producing up to 145 kg of high-quality Flake per 24 hours.
Hoshizaki FM ice makers generate quality granular ice, such as Flake or Nugget ice.

In cocktails, the dry and hard ice nuggets are the ideal cooling agent, as they deliver just the right amount of dilution, especially for strong-spirited drinks, for example, Mojitos and Tiki Cocktails. Hoshizaki nugget ice has become popular for mocktails with a high sugar content, as well as fruit and vegetable smoothies.

The light-textured flake ice has a quick cooling effect, creating an environment of uniform temperatures without causing unpleasant freezer burn. This is why Hoshizaki Flake ice is highly popular and considered the ideal material to prepare and layer hygienic and attractive food displays. The dimensions (W x D x H) of the FM-120KE(SA) are 640 x 600 x 800 mm.

Get quote View spec sheet

Key features Specifications Documentation Accessories

Key features

The FM-120KE(SA) uses refrigerant R134a.

Material

The exterior is made of stainless steel. The closed water circuit provides maximum protection against any type of contamination during the entire ice production process. All Hoshizaki machines are easy to use, clean, and maintain.

Unique Technology

The FM series has a worktime-based replacement system, which can be monitored with an intuitive control display for preventive maintenance. Hoshizaki was the first to introduce an automated water circuit rinse cycle, to avoid harmful mineral residues from clogging the hydraulic system and maintaining top sanitary conditions.

Smart Design

Like all Hoshizaki Ice makers, the FM-120KE(SA) is designed to last and comes with smart design extras. The Nugget ice maker uses carbon graphite bushings instead of conventional ball bearings allows the machine to work entirely without grease. Here, the absence of moving parts prevents wear and tear, while the water-lubricated bearings protect the system from unpleasant calcification and bacterial contamination.

Perfect Fit

With outside dimensions W x D x H of mm, the FM-120KE(SA) is compact and makes a perfect fit for small spaces.

Plug&Play

The smart plug-and-play design guarantees an extremely easy and quick set-up.

Specifications

Specification	Value
Item number	F080-C831
Model name	FM-120KE(SA)
Ice maker type	Flake ice maker
Brand	Hoshizaki
Product configuration	Self Contained
Warranty period	2 Years on Parts & Labour
Country of origin	UK
Accessories included	Installation kit, Scoop
Title	Flaker, Self-Contained
Please observe	This type of icemaker is on special order only. Please take longer lead times into consideration.
Corresponding water filters	4HC-H Single Water Filter, 4HC Replacement Cartridge
Width	640 mm
Width (packed)	746 mm
Depth	600 mm
Depth (packed)	706 mm
Height	800 mm
Height (packed)	887 mm
Volume (packed)	0.4672 m³
Dimensions legs	Including legs at 89 mm
Electric Consumption	0.55 kW
Ambient temperature (maximum)	40 °C
Ambient temperature (minimum)	5 °C
Voltage range (Rated Voltage)	±10%
Water supply pressure (maximum)	0.8MPa (8bar)
Water supply pressure (minimum)	0.05MPa (0.5bar)
Water supply temperature (maximum)	35 °C
Water supply temperature (minimum)	5 °C
Electrical circuit breaker protection	10 A
Exterior	Stainless steel AISI 441, Galvanized steel (Rear)
Gross weight	82 kg
Net weight	71 kg
Heat Rejection (AT 32°C, WT 21°C)	0.91 kW
Power supply	1/220 - 230V/60Hz
Storage bin capacity	26 kg
Cooling system	Air Cooled
Ice type	Flake
Ice production	145
Water consumption - Air cooled ice makers	0.145
CO2 equivalent	314.6 kg
GWP	1430 GWP
Refrigerant	0.22 kg
Refrigerant type	R134a
SKU	F080-C831
