Premier K 3 A DL DL 2D L E 3-Section Refrigerated Counter

Gastronomy counters

The Premier K 3 A DL DL 2D L E is a 3-Section Refrigerated Counter with a net internal volume of 280 l.

This 1/1 GN workstation on legs has outside dimensions W x D x H of 1755 x 700 x 884.2/934.2 mm.

Get quote View spec sheet

Key features Specifications Documentation Accessories

Key features

PREMIER counters and cabinets are designed to recover the inside temperature rapidly after each door opening and defrosting.

SEAMLESS KITCHEN DESIGN

Thanks to the smart front venting design, no air flow is required to the underneath, sides, or back of the unit. This allows seamless integration into your kitchen design

EASY MAINTENANCE

The compartmentalized cooling unit is extractable for easy maintenance.

HYGIENE & COOLING EFFICIENCY

The wide magnetic gaskets are removable for easy cleaning. The triple insulation area provides an effective seal, reducing escaping cold air for maximum efficiency.

ERGONOMIC DESIGN

PREMIER counters strike with ergonomic design features, such as anti-tilt shelves, drawers with pull-out stops, extra-long drawer telescopic rails, and full-length handles.

VAST VARIETY

With PREMIER counters you can choose the workplace that fits into your individual kitchen routine. Select from a wide counter portfolio with different combinations of worktops, doors, drawers, legs /castors/electric elevation, temperature ranges, and accessories.

MORE FEATURES:

Soft Closing Drawer (optional)

Different worktop options & insulation board

Increased body height of 750mm

Possibility to extend the height of castors by 50 mm with Castor Extension Kit (optional accessory)

Specifications

Specification	Value
Item number	311000113100
Model name	Premier K 3 A DL DL 2D L E
Brand	Hoshizaki
Warranty period	6 Years on Parts & Labour - based on country agreement
Country of origin	Turkey
Accessories included	2 grey shelves per door section
Title	3-Section Refrigerated Counter
Equipped with	Stainless steel worktop, 2 door sections each with 2 grey shelves and 1 drawer section with 2 x 1/2 drawers
Extended spec sheets approved	1
Width	1755 mm
Width (packed)	1783 mm
Depth	700 mm
Depth (packed)	730 mm
Height including legs (minimum)	884.2 mm
Height including legs (maximum)	934.2 mm
Height (packed)	1081 mm
Volume (packed)	1.41 l
Energy consumption	525 kWh
Energy efficiency class	A
Energy efficiency class standard	ISO 22041-2019
Energy Efficiency Index (EEI)	20.95 EEI
Number of shelves	4
Number of shelves per section	2
Shelf size	1/1 GN
Climate class	5 (max. ambient 40°C w/ 40% RH)
Connection load	125 kW
Exterior	Stainless steel AISI 304
Interior	Stainless steel AISI 304
Gross weight	151 kg
Insulation thickness	60 mm
Insulation type	Polyurethane
Legs / Castors	H = 130-180 mm (L)
Net usable volume	280 l
Net weight	138 kg
Number of sections	3 sections
Power supply	230V, 50Hz
Sound level	43 dB
Temperature range	+2/+12°C
Volume, gross	463 l
Volume, net	280 l
Worktop options	Flat worktop (A)
Cooling system	Built-in cooling system
Product type	Counters
Configuration of sections	Drawer section with 2 x 1/2 drawers, Models with door section
Refrigeration capacity	350
Optional Extras	Set of legs 125-200 mm Set of legs 130-180 mm Set of castors 125 mm Set of castors 150 mm Set of castors 200 mm Castor Extension Kit (extends height of castors by 50 mm) Stainless shelf, 325 x 530mm Grey shelf, 325 x 530mm Shelf supports, 2 of Door section Drawer section with 2 x 1/2 drawers Drawer section with 3 x 1/3 drawers Soft-close drawer Conversion Kit (for retrofit) Flat worktop Flat worktop with 50mm splashback Flat worktop with 100mm splashback
CO2 equivalent	0.195 kg
GWP	3 GWP
Refrigerant	0.065 kg
Refrigerant type	R290
Model	17
Pricelist headline label counters	REFRIGERATOR WITH WORKTOP TYPE A, A1 OR A5
Pricelist notification (short)	Models with RU1 valve prepared for external cooling system are compatible with the following refrigerants: R448A, R449A. In addition the CO2 models prepared for external cooling system are compatible with refrigerant R744 (CO2). Lead time approx. 8 weeks.
Pricelist notification (long)	Remote models are available
SKU	311000113100

Documentation

Documentation
DWG files	Download
Declaration of conformity	Download
PREMIER_3_SEC._UC_DIMENSIONAL_DRAWING_1_SS.pdf	Download
2D_dimensions.pdf	Download
H_EL_PREMIER_K_3_A_DL_DL_2D.pdf	Download
Instruction manual	Download
COOLING_CIRCUIT_DIAGRAM_FOR_CABINET_OF_PREMIER_UNDERCOUNTER.PDF	Download
Spec sheet	Download
PREMIER_UNDERCOUNTER__UC__REFRIGERATOR_WIRING_DIAGRAM.pdf	Download
