960700288

BAKER F 70 LCG L2 25B

Baker cabinets
C

The GRAM BAKER F 70 LCG L2 25B  is a with a net internal volume of  383 Ltr.



Generations of bakeries, confectioners, and patisseries are trusting GRAM BAKER storage and process cabinets to accommodate their bakery products. The GRAM air circulation system is key to maintain correct and uniform temperatures inside the cabinet. The air is exhausted and refrigerated before being directed back into the cabinet, circulating around all food items. Thus, unwanted dehydration and skin forming of doughs can be avoided almost entirely.

Product not available
Get quote View spec sheet

Key features

Preserving Quality

Both storage and process cabinets come with built-in functionalities that preserve the quality of your bakery products at all times.



Low Running Costs

The energy-efficient refrigeration technology implemented in this wide line-up of storage cabinets can help saving running costs on a day-to-day basis.



Built-in Safety

All BAKER Cabinets come with a controller equipped with safety functions: Door alarm, alarms for high-temperature levels, or when the cleaning of the condenser filter is required to avoid overheating. A top panel perfectly protects the controller from water splashes.



Designed for Bakers

The GRAM BAKER series strikes with features, specifically designed for the requirements of bakery businesses. The cabinet meets standard bakery tray sizes and the support rails can be individually positioned.



The BAKER F 70 LCG L2 25B comes with the following extras:

Right-hand hinged door with lock

Air circulation system

Dry cooling and controlled thawing (M versions)

Automatic defrost and reevaporation of water



Specifications

Specification Value
Item number 960700288
Model name BAKER F 70 LCG L2 25B
Brand Gram
Warranty period 5 Years on Parts & Labour
Equipped with Right hand hinged reversible door with lock, automatic door closing and pedal door opener, 25 pairs of adjustable trayslides (46x61 cm). LED light
Width 700 mm
Depth 905 mm
Height 2125 mm
Energy consumption 1508 kWh
Energy efficiency class C
Product availability -- Not available
Connection load 368 kW
Exterior White Finish
Interior Stainless
Gross weight 136 kg
Insulation thickness 70 mm
Insulation type Cyclopentane
Legs / Castors H = 135-200 mm (L)
Net usable volume 383 l
Net weight 136 kg
Power supply 230V, 50Hz
Sound level 47.3 dB
Temperature range -25/-5°C
Volume, gross 610 l
Volume, net 383 l
Door Type Solid Door
Refrigeration capacity 490
CO2 equivalent 0.246 kg
GWP 3 GWP
Refrigerant 0.082 kg
Refrigerant type R290
SKU 960700288
