ACR-130DG-LR-RRC-L1 2-Section Refrigerated Counter

Gastronomy counters

The Hoshizaki ACR-130DG-LR-RRC-L1 is a 2-Section Refrigerated Counter with a net internal volume of 171 l.

This refrigerated counter not only meets rigorous kitchen demands but also boosts operational efficiency with its thoughtful design and durable construction.

Get quote View spec sheet

Key features Specifications Documentation Accessories

Key features

Efficient Cooling

The climate class 5 system includes fan-assisted cooling to maintain optimal temperatures up to +40°C, ensuring food stays fresh, and features automatic defrost with re-evaporation of defrost water.

Hygienic Surfaces

Both interior and exterior are made of stainless steel, offering a robust, food-safe environment that is easy to clean and maintain.

User-Friendly Design

Features like reversible doors, anti-tilt shelves, and removable magnetic door gaskets with triple insulation facilitate seamless operation and maintenance, for a smooth kitchen workflow.

Convenient Extras

Includes a low-maintenance condenser, and a compact slide-out refrigeration unit for effortless servicing, reducing downtime and operational hassles.

Specifications

Specification	Value
Item number	889000840
Model name	ACR-130DG-LR-RRC-L1
Brand	Hoshizaki
Warranty period	5 Years on Parts & Labour - based on country agreement
Country of origin	Turkey
Title	2-Section Refrigerated Counter
Accessories included	2 grey shelves per section
Equipped with	Stainless steel worktop, 2 door sections each with 2 grey shelves
Extended spec sheets approved	1
Width	1314 mm
Width (packed)	1364 mm
Depth	700 mm
Depth (packed)	760 mm
Height including legs (minimum)	830 mm
Height including legs (maximum)	880 mm
Height (packed)	1050 mm
Volume (packed)	1.09 l
Energy consumption	721 kWh
Energy efficiency class	B
Energy efficiency class standard	ISO 22041-2019
Energy Efficiency Index (EEI)	32.39 EEI
Number of shelves	4
Number of shelves per section	2
Shelf size	1/1 GN
Climate class	5 (max. ambient 40°C w/ 40% RH)
Connection load	180 W
Exterior	Stainless Steel
Interior	Stainless
Gross weight	122 kg
Insulation thickness	50 mm
Insulation type	Cyclopentane
Legs / Castors	H = 130-180 mm (L)
Net usable volume	171 l
Net weight	95 kg
Number of sections	2 sections
Power supply	230V, 50Hz
Sound level	51 dB
Temperature range	-2/+8°C
Volume, gross	301 l
Volume, net	171 l
Cooling system	Built-in cooling system
Door Type	Solid Door
Product type	Counters
Configuration of sections	Models with door section
Refrigeration capacity	367
Optional Extras	Set of legs for 835-900 mm Counter-top (L2) Set of 4 Castors for 850 mm Counter-top (C1) Set of 4 Castors for 900 mm Counter-top (C2) Castor Extension Kit (extends height of castors by 50mm) Flat worktop with 100 mm splashback Drawer section with 2 x 1/2 drawers Drawer section with 3 x 1/3 drawers * Shelf support - Left Shelf support - Right Stainless shelf Grey shelf *3 drawer section is not available next to the compressor housing
CO2 equivalent	0.165 kg
GWP	3 GWP
Refrigerant	0.055 kg
Refrigerant type	R290
Pricelist headline label counters	REFRIGERATOR WITH WORKTOP TYPE A OR A1
SKU	889000840

Documentation

Documentation
Declaration of conformity	Download
ACR_130DG_LR.pdf	Download
Instruction manual	Download

Accessories

Accessory name	Item number
Shelf stainless, 325 x 530 mm	760660010
Set of castors 150 mm (2 x braked and 2 x unbreaked)	760660011
Set of castors 200 mm (2 x braked and 2 x unbreaked)	760660012
Set of legs 130-180 mm	760660118
Set of legs 125-200 mm	760660119
Castor Extension Kit (extends height of castors by 50 mm)	760660453
