ADVANCE MD K 180 SW N E Lodówka wielopoziomowa z solidny panel boczny
221183150
Czytaj więcej
The Premier K 3 SL DL DL DR C U is a 3-Section Refrigerated Counter with Saladette worktop with a net internal volume of 0 Ltr.
This 1/1 GN workstation on castors has dimensions W x D x H of 1755 x 700 x 998 (including castors) mm.
Uzyskaj wycenę Zobacz specyfikacjęPREMIER counters and cabinets are designed to recover the inside temperature rapidly after each door opening and defrosting.
SEAMLESS KITCHEN DESIGN
Thanks to the smart front venting design, no air flow is required to the underneath, sides, or back of the unit. This allows seamless integration into your kitchen design
EASY MAINTENANCE
The compartmentalized cooling unit is extractable for easy maintenance.
HYGIENE & COOLING EFFICIENCY
The wide magnetic gaskets are removable for easy cleaning. The triple insulation area provides an effective seal, reducing escaping cold air for maximum efficiency.
ERGONOMIC DESIGN
PREMIER counters strike with ergonomic design features, such as anti-tilt shelves, drawers with pull-out stops, extra-long drawer telescopic rails, and full-length handles.
VAST VARIETY
With PREMIER counters you can choose the workplace that fits into your individual kitchen routine. Select from a wide counter portfolio with different combinations of worktops, doors, drawers, legs /castors, temperature ranges, and accessories.
MORE FEATURES:
Soft Closing Drawer (optional)
Different worktop options & insulation board
Increased body height of 750mm
Possibility to extend the height of castors by 50 mm with Castor Extension Kit (optional accessory)
| Specyfikacja | Value |
| Numer Artykułu | 311060112210 |
| Nazwa modelu | Premier K 3 SL DL DL DR C U |
| Marka | Hoshizaki |
| Okres gwarancji | 6 lat na części zamienne i robociznę |
| KRAJ POCHODZENIA | Turcja |
| Tytuł | 3-Section Refrigerated Counter with Saladette worktop |
| AKCESORIA W KOMPLECIE | 2 grey shelves per door section |
| Wyposażony w | Saladette worktop with an insulated hinged night lid, 3 door sections each with 2 grey shelves |
| Szerokość | 1755 mm |
| Szerokość (w opakowaniu) | 1783 mm |
| Głębokość | 700 mm |
| Głębokość (w opakowaniu) | 730 mm |
| Wysokość | 998 mm |
| Wysokość (w opakowaniu) | 1242 mm |
| Objętość (w opakowaniu) | 1.49 m³ |
| liczba rusztów | 6 |
| liczba krat na sekcję | 2 |
| Rozmiar prusztu | 1/1 GN |
| Klasa klimatyczna | 5 |
| Obciążenie przyłącza | 280 W |
| OBUDOWA | Stal nierdzewna AISI 304 |
| Wnętrze | Stal nierdzewna AISI 304 |
| Waga brutto | 148 kg |
| Grubość izolacji | 60 mm |
| Rodzaj izolacji | Polyurethane |
| Nóżki / Kółka | H = 150 mm (C) |
| Waga netto | 135 kg |
| Ilość sekcji | 3 sections |
| Zasilanie | 230V, 50Hz |
| Zakres temperatur | +2/+12°C |
| Objętość, brutto | 463 l |
| Opcje blatu | Blat roboczy Salaterka SL |
| System chłodzenia | Built-in cooling system |
| Rodzaj produktu | Counters |
| Konfiguracja drzwi/szuflady | Models with door section |
| Wydajność chłodzenia | 633 |
| Opcjonalne dodatki | Set of legs 100-150mm Set of legs 125-200mm Set of legs 130-180mm Set of castors 125mm Set of castors 150mm Mini Castors - 2 braked and 2 unbraked 88mm Stainless shelf, 325 x 530mm Grey shelf, 325 x 530mm Shelf supports, 2 of Door section |
| Ekwiwalent CO2 | 0.27 kg |
| GWP | 3 GWP |
| Czynnik chłodniczy | 0.09 kg |
| Rodzaj czynnika chłodniczego | R290 |
| Model | 2 |
| Cennik Etykieta nagłówkowa Lady chłodnicze | REFRIGERATOR WITH SALADETTE WORKTOP |
| Pricelist notification (short) | Models with RU1 valve prepared for external cooling system are compatible with the following refrigerants: R448A, R449A. In addition the CO2 models prepared for external cooling system are compatible with refrigerant R744 (CO2). Lead time approx. 8 weeks. |
| Pricelist notification (long) | Remote models are available |
| SKU | 311060112210 |
| Dokumentacja | |
| Deklaracja zgodności | Pobierz |
| Rysunki wymiarowe (główne) | Pobierz |
| Instrukcja obsługi | Pobierz |
| COOLING_CIRCUIT_DIAGRAM_FOR_CABINET_OF_PREMIER_UNDERCOUNTER.PDF | Pobierz |
| Podręcznik serwisowy | Pobierz |
| Części zamienne / lista części | Pobierz |
| PREMIER_PREP_SALADETTE_WIRING_DIAGRAM.pdf | Pobierz |
| pliki bim/rfa | Pobierz |
| Nazwa akcesorium | Numer przedmiotu |
| Półka ze stali nierdzewnej, 325 x 530 mm | 760660010 |
| Zestaw kółek 150 mm (2 x z hamulcem i 2 x bez hamulca) | 760660011 |
| Zestaw kółek 200 mm (2 x z hamulcem i 2 x bez hamulca) | 760660012 |
| Zestaw kółek 125 mm (2 x z hamulcem i 2 x bez hamulca) | 760660022 |
| Zestaw nóg 130–180 mm | 760660118 |
| Zestaw nóg 125–200 mm | 760660119 |
| Zestaw przedłużający do kółek (zwiększa wysokość kółek o 50 mm) | 760660453 |
| Sekcja drzwiowa | 760660482 |
| Wsporniki półek x 2 | 760660545 |
| Półka szara 325 x 530 mm | 760660546 |
| Zestaw nóg 100–150 mm | 760660700 |
