311060112210

Premier K 3 SL DL DL DR C U 3-Section Refrigerated Counter with Saladette worktop

Chłodnictwo

The Premier K 3 SL DL DL DR C U is a 3-Section Refrigerated Counter with Saladette worktop with a net internal volume of  0 Ltr.



This 1/1 GN workstation on castors has dimensions W x D x H  of  1755 x 700 x 998 (including castors) mm.

Uzyskaj wycenę Zobacz specyfikację

Najważniejsze cechy

PREMIER counters and cabinets are designed to recover the inside temperature rapidly after each door opening and defrosting.



SEAMLESS KITCHEN DESIGN

Thanks to the smart front venting design, no air flow is required to the underneath, sides, or back of the unit. This allows seamless integration into your kitchen design



EASY MAINTENANCE

The compartmentalized cooling unit is extractable for easy maintenance.



HYGIENE & COOLING EFFICIENCY

The wide magnetic  gaskets are removable for easy cleaning. The triple insulation area provides an effective seal, reducing escaping cold air for maximum efficiency.



ERGONOMIC DESIGN

PREMIER counters strike with ergonomic design features, such as anti-tilt shelves, drawers with pull-out stops, extra-long drawer telescopic rails, and full-length handles.



VAST VARIETY

With PREMIER counters you can choose the workplace that fits into your individual kitchen routine.  Select from a wide counter portfolio with different combinations of worktops, doors, drawers, legs /castors, temperature ranges, and accessories.



MORE FEATURES:

Soft Closing Drawer (optional)

Different worktop options & insulation board

Increased body height of 750mm

Possibility to extend the height of castors by 50 mm with Castor Extension Kit (optional accessory)

Specyfikacje

Specyfikacja Value
Numer Artykułu 311060112210
Nazwa modelu Premier K 3 SL DL DL DR C U
Marka Hoshizaki
Okres gwarancji 6 lat na części zamienne i robociznę
KRAJ POCHODZENIA Turcja
Tytuł 3-Section Refrigerated Counter with Saladette worktop
AKCESORIA W KOMPLECIE 2 grey shelves per door section
Wyposażony w Saladette worktop with an insulated hinged night lid, 3 door sections each with 2 grey shelves
Szerokość 1755 mm
Szerokość (w opakowaniu) 1783 mm
Głębokość 700 mm
Głębokość (w opakowaniu) 730 mm
Wysokość 998 mm
Wysokość (w opakowaniu) 1242 mm
Objętość (w opakowaniu) 1.49 m³
liczba rusztów 6
liczba krat na sekcję 2
Rozmiar prusztu 1/1 GN
Klasa klimatyczna 5
Obciążenie przyłącza 280 W
OBUDOWA Stal nierdzewna AISI 304
Wnętrze Stal nierdzewna AISI 304
Waga brutto 148 kg
Grubość izolacji 60 mm
Rodzaj izolacji Polyurethane
Nóżki / Kółka H = 150 mm (C)
Waga netto 135 kg
Ilość sekcji 3 sections
Zasilanie 230V, 50Hz
Zakres temperatur +2/+12°C
Objętość, brutto 463 l
Opcje blatu Blat roboczy Salaterka SL
System chłodzenia Built-in cooling system
Rodzaj produktu Counters
Konfiguracja drzwi/szuflady Models with door section
Wydajność chłodzenia 633
Opcjonalne dodatki Set of legs 100-150mm    Set of legs 125-200mm                   Set of legs 130-180mm Set of castors 125mm Set of castors 150mm Mini Castors - 2 braked and 2 unbraked 88mm                   Stainless shelf, 325 x 530mm      Grey shelf, 325 x 530mm               Shelf supports, 2 of    Door section
Ekwiwalent CO2 0.27 kg
GWP 3 GWP
Czynnik chłodniczy 0.09 kg
Rodzaj czynnika chłodniczego R290
Model 2
Cennik Etykieta nagłówkowa Lady chłodnicze REFRIGERATOR WITH SALADETTE WORKTOP
Pricelist notification (short) Models with RU1 valve prepared for external cooling system are compatible with the following refrigerants: R448A, R449A. In addition the CO2 models prepared for external cooling system are compatible with refrigerant R744 (CO2). Lead time approx. 8 weeks.
Pricelist notification (long) Remote models are available
SKU 311060112210

Dokumentacja

Dokumentacja
Deklaracja zgodności Pobierz
Rysunki wymiarowe (główne) Pobierz
Instrukcja obsługi Pobierz
COOLING_CIRCUIT_DIAGRAM_FOR_CABINET_OF_PREMIER_UNDERCOUNTER.PDF Pobierz
Podręcznik serwisowy Pobierz
Części zamienne / lista części Pobierz
PREMIER_PREP_SALADETTE_WIRING_DIAGRAM.pdf Pobierz
pliki bim/rfa Pobierz

Akcesoria

Nazwa akcesorium Numer przedmiotu
Półka ze stali nierdzewnej, 325 x 530 mm 760660010
Zestaw kółek 150 mm (2 x z hamulcem i 2 x bez hamulca) 760660011
Zestaw kółek 200 mm (2 x z hamulcem i 2 x bez hamulca) 760660012
Zestaw kółek 125 mm (2 x z hamulcem i 2 x bez hamulca) 760660022
Zestaw nóg 130–180 mm 760660118
Zestaw nóg 125–200 mm 760660119
Zestaw przedłużający do kółek (zwiększa wysokość kółek o 50 mm) 760660453
Sekcja drzwiowa 760660482
Wsporniki półek x 2 760660545
Półka szara 325 x 530 mm 760660546
Zestaw nóg 100–150 mm 760660700
