The Premier K 2 A DL DR L E is a 2-Section Refrigerated Counter with a net internal volume of 192 l.
This 1/1 GN workstation on legs has outside dimensions W x D x H of 1314 x 700 x 884.2/934.2 mm.
Uzyskaj wycenę View spec sheetPREMIER counters and cabinets are designed to recover the inside temperature rapidly after each door opening and defrosting.
SEAMLESS KITCHEN DESIGN
Thanks to the smart front venting design, no air flow is required to the underneath, sides, or back of the unit. This allows seamless integration into your kitchen design
EASY MAINTENANCE
The compartmentalized cooling unit is extractable for easy maintenance.
HYGIENE & COOLING EFFICIENCY
The wide magnetic gaskets are removable for easy cleaning. The triple insulation area provides an effective seal, reducing escaping cold air for maximum efficiency.
ERGONOMIC DESIGN
PREMIER counters strike with ergonomic design features, such as anti-tilt shelves, drawers with pull-out stops, extra-long drawer telescopic rails, and full-length handles.
VAST VARIETY
With PREMIER counters you can choose the workplace that fits into your individual kitchen routine. Select from a wide counter portfolio with different combinations of worktops, doors, drawers, legs /castors/electric elevation, temperature ranges, and accessories.
MORE FEATURES:
Soft Closing Drawer (optional)
Different worktop options & insulation board
Increased body height of 750mm
Possibility to extend the height of castors by 50 mm with Castor Extension Kit (optional accessory)
Specyfikacja | Value |
Numer Artykułu | 211000012100 |
Nazwa modelu | Premier K 2 A DL DR L E |
Marka | Hoshizaki |
Okres gwarancji | 6 lata na części zamienne i robociznę |
KRAJ POCHODZENIA | Turkey |
Tytuł | 2-Section Refrigerated Counter |
AKCESORIA W KOMPLECIE | 2 grey shelves per door section |
Wyposażony w | Stainless steel worktop, 2 door sections each with 2 grey shelves |
Szerokość | 1314 mm |
Szerokość (w opakowaniu) | 1340 mm |
Głębokość | 700 mm |
Głębokość (w opakowaniu) | 730 mm |
Wysokość z nogami (minimalna) | 884.2 mm |
Wysokość łącznie z nogami (maksimum) | 934.2 mm |
Wysokość (w opakowaniu) | 1081 mm |
Objętość (w opakowaniu) | 1.06 l |
Zużycie energii | 317 kWh |
Klasa energooszczędności | A+ |
Standardowa klasa energooszczędności | ISO 22041-2019 |
Indeks efektywności energetycznej (EEI) | 13.9 EEI |
liczba rusztów | 4 |
liczba krat na sekcję | 2 |
Rozmiar prusztu | 1/1 GN |
Klasa klimatyczna | 5 |
Obciążenie przyłącza | 115 kW |
Zewnętrzny | Stala nierdzewna AISI 304 |
Wnętrze | Stainless steel AISI 304 |
Waga brutto | 110 kg |
Grubość izolacji | 60 mm |
Rodzaj izolacji | Polyurethane |
Nóżki / Kółka | H = 130-180 mm (L) |
Objętość powierzchni netto | 192 l |
Waga netto | 98 kg |
Ilość sekcji | 2 sections |
Zasilanie | 230V, 50Hz |
Poziom głośności | 43 dB |
Zakres temperatur | +2/+12°C |
Objętość, brutto | 301 l |
Objętość, netto | 192 l |
Opcje blatu | Flat worktop (A) |
System chłodzenia | Built-in cooling system |
Rodzaj produktu | Counters |
Konfiguracja drzwi/szuflady | Models with door section |
Wydajność chłodzenia | 206 |
Opcjonalne dodatki | Set of legs 125-200 mm Set of legs 130-180 mm Set of castors 125 mm Set of castors 150 mm Set of castors 200 mm Castor Extension Kit (extends height of castors by 50 mm) Stainless shelf, 325 x 530 mm Grey shelf, 325 x 530 mm Shelf supports, 2 of Door section Drawer section with 2 x 1/2 drawers Drawer section with 3 x 1/3 drawers Flat worktop Flat worktop with 50mm splashback Flat worktop with 100mm splashback |
Ekwiwalent CO2 | 0.21 kg |
GWP | 3 GWP |
Czynnik chłodniczy | 0.07 kg |
Rodzaj czynnika chłodniczego | R600a |
Cennik Etykieta nagłówkowa Lady chłodnicze | REFRIGERATOR WITH WORKTOP TYPE A, A1 OR A5 |
Pricelist notification (short) | Models with RU1 valve prepared for external cooling system are compatible with the following refrigerants: R448A, R449A. In addition the CO2 models prepared for external cooling system are compatible with refrigerant R744 (CO2). Lead time approx. 8 weeks. |
Pricelist notification (long) | Remote models are available |
SKU | 211000012100 |
Dokumentacja | |
DWG files | Pobierz |
Declaration of conformity | Pobierz |
PREMIER_2_SEC._UC_DIMENSIONAL_DRAWING_1_SS.pdf | Pobierz |
H_EL_PREMIER_K_2_A_DL_DR.pdf | Pobierz |
Instruction manual | Pobierz |
COOLING_CIRCUIT_DIAGRAM_FOR_CABINET_OF_PREMIER_UNDERCOUNTER.PDF | Pobierz |
PREMIER_UNDERCOUNTER__UC__REFRIGERATOR_WIRING_DIAGRAM.pdf | Pobierz |
