DCM-120KE-HC (UK) Dispenser, Ice & Water

Dispensers

This Hoshizaki DCM-120KE-HC (UK) is an ice/water dispenser producing up to 125 kg of high-quality servings of cubelet ice and/or water per 24 hours. Most commonly, Hoshizaki dispensers are used, where a quick, efficient, and food-safe serving of ice-water combinations is needed.

Get quote View spec sheet

Key features Specifications Documentation Accessories

Key features

Dispensers play a crucial role when business owners want to provide ice and/or water for self-service. The three steps of quality ice production, protected ice storage, as well as quick service of ice are all combined in one device – with the help of only one button your refreshment is ready in seconds.

With DCM DISPENSERS the user can select from these options:

• Cubelet ice only

• Cubelet ice and water

• Water only

Specifications

Specification	Value
Item number	L032-C101
Model name	DCM-120KE-HC (UK)
Brand	Hoshizaki
Product configuration	Self Contained
Warranty period	2 Years on Parts & Labour
Country of origin	UK
Title	Dispenser, Ice & Water
Width	350 mm
Width (packed)	440 mm
Depth	585 mm
Depth (packed)	655 mm
Height including legs (minimum)	815 mm
Height including legs (maximum)	830 mm
Height (packed)	1026 mm
Volume (packed)	0.2957 m³
Dimensions legs	Including legs at 50-65 mm
Electric Consumption	0.45 kW
Energy consumption	0.4 kWh
Ambient temperature (maximum)	40 °C
Ambient temperature (minimum)	5 °C
Water supply pressure (maximum)	0.78MPa (7.8bar)
Water supply pressure (minimum)	0.05MPa (0.5bar)
Water supply temperature (maximum)	35 °C
Water supply temperature (minimum)	5 °C
Electrical circuit breaker protection	10 A
Exterior	Stainless steel (Side, Rear), ABS molding (Front, Top, Drain pan)
Gross weight	65 kg
Heat Rejection (AT 32°C, WT 21°C)	0.78 kW
Net weight	56 kg
Power supply	1/220 - 240V/50Hz
Storage bin capacity	4 kg
Cooling system	Air Cooled
Ice type	Cubelet + Water
Ice production	125
Water consumption - Air cooled ice makers	0.125
CO2 equivalent	0.285 kg
Refrigerant	0.095 kg
Refrigerant type	R290
SKU	L032-C101
