960739000

ECO PLUS KG 70 CCF CO2 L2 4S A (AKCC)

Gastronomy cabinets
Category not yet regulated

ECO EURO 60 is the name of one of the new series in the PLUS range. These new cabinets combine stylish design with high functionality and low energy consumption. • The controls are concealed behind the top panel, protected against splashing water. • Design principle of "no broken surfaces" makes the cabinets easy to clean. • The distinctive aluminum profiles stretching from top to bottom on both sides of the cabinet impart strength and enhance appearance. • The modular rails can go directly in the dishwasher. • Pedal opener with finesse - read more in the brochure. Shelf dimensions are the standard Euronorm, i.e. 40x60 cm.

Product not available
Get quote View spec sheet

Key features

Food Safety

The efficient air circulation system helps to maintain perfect storage temperatures. Designed to recover the inside temperature rapidly after each door opening. Temperatures for optimal food safety and enhanced shelf-life are maintained for climate class 5.



Low Running Costs

Tracking and controlling the lifetime costs of equipment is key to any successful professional kitchen. All ECO cabinets strike with excellent energy ratings and help you save running costs on a daily level.

The Energy Efficiency Class of the ECO PLUS KG 70 CCF CO2 L2 4S A (AKCC) is Category not yet regulated.



Comfortable Work Environment

The ECO range contributes to a healthier work environment with low noise levels of approximately 45 dB(A) when the compressor is running.



Hygiene & Ergonomic Design

Thanks to the rounded corners and smooth surface, frequented cleaning routines become a quick and simple task. All Cabinets have self-closing doors with full-height handles providing easy access for cleaning. The patented pedal door opener can be placed on the left or right side.



Smart Design

The ECO series strikes with its energy efficiency, food-safe design, and smart extras such as the patented pedal door opener. This helpful feature can be placed on the left or right side. While carrying goods, the cabinet door can be opened with a quick foot tap.

Specifications

Specification Value
Item number 960739000
Model name ECO PLUS KG 70 CCF CO2 L2 4S A (AKCC)
Brand Gram
Equipped with Right hand hinged reversible glass door, automatic door closing, pedal door opener, 4 stainless steel shelves, LED lighting
Width 700 mm
Depth 905 mm
Height 2125 mm
Energy efficiency class Category not yet regulated
Shelf size 2/1 GN deep
Product availability -- Not available
Connection load 156 kW
Exterior Stainless Steel
Interior Stainless
Gross weight 157 kg
Insulation thickness 70 mm
Insulation type Cyclopentane
Legs / Castors H = 135-200 mm (L)
Net usable volume 451 l
Net weight 157 kg
Power supply 230V, 50Hz
Temperature range +2/+12°C
Volume, gross 610 l
Volume, net 451 l
Door Type Glass door
Refrigeration capacity 300
GWP 1 GWP
Refrigerant type attOpt_remote_co2_r744
SKU 960739000

Documentation

Documentation
765042313_PLUS_70_CO2.pdf Download
Declaration of conformity Download
765042411_General_installation_and_service_manual_ECO_CO2.pdf Download
Instruction manual Download
765042194_ECO_CO2_cabinets.pdf Download
765072948_PLUS_EURO_TWIN_82_CO2.pdf Download
